Enkei PF01EVO wheels

Enkei Wheels

Enkei PF01EVO

From time attack to drifters, the PF01EVO wheel is designed to maximize the performance of 17 and 18-inch tires. When mounted on a vehicle with over fenders, the minimum inset starts from 0 mm, widening the settable tread width range. The PF01EVO wheel adopts ENKEI’s proprietary MAT process technology to ensure both the high rigidity and lightness required for an uncompromising sport wheel. ROULETTE PATTERN Our unique roulette pattern is grooved on the rim to reduce the slippage ratio between tire and rim. The roulette-pattern maintains the best condition of the wheel and tire assembly, thus achieving the highest performance during extreme acceleration and deceleration. PF01エボリューションホイール ■ スプリット5スポーク×ディープリムデザイン ■ ハードチューニングカー向けスポーツモデル 17, 18 MATTE BLACK, PEARL WHITE, OR SBK Spec-E Inspected MAT Process

Specifications

Diameter17-18 inch
Width9-10.5 inch
OffsetET0 to ET45
ConstructionMat flow formed
Bolt pattern5x112, 5x114.3, 5x120
Weight8.39 kg
FinishesGloss Black, WP, SBK
SeriesRacing Series

Sizes

SizeOffsetBolt patternCentre boreWeight
17x9ET05x114.375 mm19 lb
17x9ET125x114.375 mm19 lb
17x9ET225x114.375 mm19 lb
17x9.5ET05x114.375 mm19.05 lb
17x9.5ET125x114.375 mm19.05 lb
17x9.5ET225x114.375 mm19.05 lb
17x9.5ET355x114.375 mm19.05 lb
18x9ET255x114.375 mm18.5 lb
18x9ET355x114.375 mm18.5 lb
18x9ET455x114.375 mm18.5 lb
18x9.5ET155x12072.5 mm19.1 lb
18x9.5ET205x12072.5 mm19.85 lb
18x9.5ET455x11275 mm19.85 lb
18x9.5ET05x114.375 mm19.85 lb
18x9.5ET125x114.375 mm19.1 lb
18x9.5ET225x114.375 mm19.85 lb
18x9.5ET355x114.375 mm19.85 lb
18x9.5ET455x114.375 mm19.85 lb
18x10.5ET225x12072.5 mm20.65 lb
18x10.5ET155x114.375 mm20.65 lb
18x10.5ET225x114.375 mm20.65 lb
